| Data hold |
yes |
| Interface |
yes |
| Indication |
Graphic |
| IR interface |
no |
| Continuity test |
yes |
| Multiple display |
no |
| Peak value memory |
yes |
| Max. value storage |
yes |
| Min. value storage |
yes |
| Bluetooth interface |
yes |
| True RMS measurement |
yes |
| Frequency measurement |
yes |
| Measured value memory |
yes |
| Inductance measurement |
no |
| With display backlight |
yes |
| Capacitance measurement |
yes |
| Duty cycle measurements |
yes |
| Temperature measurement |
yes |
| Cable length measurement |
no |
| Degree of protection (IP) |
IP40 |
| Measuring range selection |
Manual/automatic |
| Analogue bar graph display |
yes |
| Measuring circuit category |
CAT IV |
| Resistance test/diode test |
yes |
| Rotational speed measuring |
no |
| Temperature measurement TC |
yes |
| Lowest resolution, frequency |
0.001 Hz |
| Power and energy measurement |
no |
| Lowest resolution temperature |
0.1 °C |
| Lowest resolution, AC current |
0.1 µA |
| Lowest resolution, AC voltage |
0.01 mV |
| Lowest resolution, DC current |
0.1 µA |
| Lowest resolution, DC voltage |
0.01 mV |
| Lowest resolution, resistance |
0.01 Ohm |
| With conductivity measurement |
yes |
| With decibel measurement (dB) |
no |
| Lowest resolution, capacitance |
0.001 µF |
| Max. frequency measuring range |
9.999 |
| Max. resistance measuring range |
50 |
| Harmonics analysis/power quality |
no |
| Max. capacitance measuring range |
10000 |
| Max. current measuring range, AC |
10 |
| Max. current measuring range, DC |
10 |
| Max. temperature measuring range |
1350 |
| Max. voltage measuring range, AC |
1000 |
| Max. voltage measuring range, DC |
1000 |
| Max. voltage measuring circuit category |
1000 |
| Analogue bar graph display analogue/logarithmical |
yes |
| Cable symmetry testing for two wire connections a-b-E |
no |
| Milliohm measurement with 4 wire technique (Kelvin connection) |
yes |
