Categories
Features
|
Data hold
|
yes
|
|
Interface
|
no
|
|
Indication
|
Graphic
|
|
IR interface
|
no
|
|
Continuity test
|
yes
|
|
Multiple display
|
no
|
|
Peak value memory
|
yes
|
|
Max. value storage
|
yes
|
|
Min. value storage
|
yes
|
|
Bluetooth interface
|
no
|
|
True RMS measurement
|
yes
|
|
Frequency measurement
|
yes
|
|
Measured value memory
|
no
|
|
Inductance measurement
|
no
|
|
With display backlight
|
yes
|
|
Capacitance measurement
|
yes
|
|
Duty cycle measurements
|
yes
|
|
Temperature measurement
|
yes
|
|
Cable length measurement
|
no
|
|
Degree of protection (IP)
|
IP67
|
|
Measuring range selection
|
Manual/automatic
|
|
Analogue bar graph display
|
yes
|
|
Measuring circuit category
|
CAT IV
|
|
Resistance test/diode test
|
yes
|
|
Rotational speed measuring
|
no
|
|
Temperature measurement TC
|
yes
|
|
Lowest resolution, frequency
|
0.001 Hz
|
|
Power and energy measurement
|
no
|
|
Lowest resolution temperature
|
1 °C
|
|
Lowest resolution, AC current
|
0.1 µA
|
|
Lowest resolution, AC voltage
|
0.01 mV
|
|
Lowest resolution, DC current
|
0.1 µA
|
|
Lowest resolution, DC voltage
|
0.01 mV
|
|
Lowest resolution, resistance
|
0.1 Ohm
|
|
With conductivity measurement
|
yes
|
|
With decibel measurement (dB)
|
no
|
|
Lowest resolution, capacitance
|
0.001 µF
|
|
Max. frequency measuring range
|
9.999
|
|
Max. resistance measuring range
|
60
|
|
Harmonics analysis/power quality
|
no
|
|
Max. capacitance measuring range
|
10000
|
|
Max. current measuring range, AC
|
10
|
|
Max. current measuring range, DC
|
10
|
|
Max. temperature measuring range
|
1000
|
|
Max. voltage measuring range, AC
|
1000
|
|
Max. voltage measuring range, DC
|
1000
|
|
Max. voltage measuring circuit category
|
1000
|
|
Analogue bar graph display analogue/logarithmical
|
yes
|
|
Cable symmetry testing for two wire connections a-b-E
|
no
|
