TeSys D - time delay auxiliary contact block - 1 NO + 1 NC screw clamp terminals
TeSys D time delay auxiliary contact block, for contactors LC1D, LC1F and control relays CAD. It provides 1NO+1NC contacts rated up to 10A 690V AC, Off-delay setting range 1-30s, connection by screw clamp terminals. A delay of 40ms is ensured between opening of NC contact and closing of NO contact. Clip-on front mounting, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Sustainability compliant.
Product identifiers
SKU: LADS2
EAN: 3389110386103
GTIN: 3389110386103
MPN: LADS2
Loyalty points:
40
Price range: £ 63.35 - £ 101.64 Excl. VAT
ETIM Group
Videos
Promotional video
Specifications
| Setting time | |
| Switching function | Operating delayed |
| Operating principle | Electronic |
| Number of contacts as change-over contact | 0 |
| Number of contacts as normally open contact | 1 |
| Number of contacts as normally closed contact | 1 |
