HB SEN P 147W 840 70DEG IP65
1 / 7
HB SEN P 147W 840 70DEG IP65
HB SEN P 147W 840 70DEG IP65 by LEDVANCE is listed by 1 electrical wholesaler on Voltimum UK, including Farnell. Trade price £246.80 excl. VAT.
Product benefits
- Multiple adjustments of sensor range, daylight detection and hold time
- High luminous efficacy
- Energy savings of up to 64 % compared to conventional high bay luminaires
- 5 years guarantee
- Suitable for use in dusty and damp locations thanks to high IP rating
Areas of application
- Replacement for high bay luminaires with mercury vapor or metal halide lamps
- Warehouses
- Logistics halls
- Industry
- High ceiling (e.g. in shopping malls, airports, commercial buildings, lobbies)
Product features
- High frequency sensor for daylight and motion detection
- Different luminous flux and beam angle for mounting heights of ~ 6 m to 10 m in 4000 K
Equipment / Accessories
- Sensor, mounting hook and mounting bracket included
- Reflectors, refractors and remote control available as separate accessory
References / Links
- For Guarantee see www.ledvance.com/guarantee
Product identifiers
SKU: 4058075603271
EAN: 4058075603271
GTIN: 4058075603271
MPN: 4058075603271
Price: £ 246.80 Excl. VAT
Categories
ETIM group
Specifications
Electrical data
| Nominal wattage | 147.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 660 mA |
| Inrush current | 48.8 A |
| Inrush current time T h50 | 368 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 4 |
| Max. number of luminaires per miniature circuit breaker C10 | 4 |
Documents
Documents and certificates
Data sheet
Documents And Certificates
User instruction / safety instructions – HIGHBAY SENSOR
Legal information – LS Insert HB Sensor P
Legal information – Legal insert HB SEN P
Legal information – Informationstext 18 Abs 4 ElektroG
Declarations of conformity UKCA – HB SEN P 840 IP65
Certificates – ENEC Certificate HB P and HB Sensor P
EPD – EPD EN HIGH BAY GEN 4 SENSOR
