SENSOR DIRECT LS-PD-7 IR CI ZB
1 / 6
SENSOR DIRECT LS-PD-7 IR CI ZB
Product benefits
- Quick and easy installation using spring clips
- Low maintenance through mains power operation
- Additional energy saving up to 50 % compare to LED On/Off installation
- Zigbee 3.0 certified device for integration to any 3rd party Zigbee Control System
- The right light at the right time at the right moment, fully autonomous
- Compatible with LEDVANCE VIVARES ZIGBEE and DIRECT EASY light management system
Areas of application
- Open office spaces
- Meeting and conference rooms
- Storage and break areas
- Classrooms
- Corridors
- Stairways
Product features
- Zigbee 3.0 certified light and presence sensor for ceiling integration
- Presence detection via passive IR element
- AC mains powered 100 V - 277 V
- Detection height up to 4 m
- Large detection area up to 7 m
- Direct commissioning via bluetooth possible
Equipment / Accessories
- Surface mounting via SENSOR CM KIT
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
References / Links
- For current information see www.ledvance.com/light-management-systems
Product identifiers
SKU: 4099854476358
EAN: 4099854476358
GTIN: 4099854476358
MPN: 4099854476358
Price: £ 0.00 Excl. VAT
Specifications
Capabilities
| Dimmable | No |
| Dimming interface | Zigbee Direct |
| Maximum installation height | 4 m |
| Detection angle | 360 ° |
| Type of installation | Ceiling integration |
Electrical data
| Nominal wattage | 0.36 W |
| Nominal voltage | 100…277 V |
| Type of current | AC |
