LN UO 1200 33 W 3000 K
LN UO 1200 33 W 3000 K
LN UO 1200 33 W 3000 K by LEDVANCE is listed by 1 electrical wholesaler on Voltimum UK, including RS Components, and currently in stock. Trade price £53.10 excl. VAT.
Product benefits
- Replacement of conventional T8 luminaires with up to 7100 lm
- Energy savings up to 60 % (compared to luminaires that use fluorescent lamps)
- Robust structure with IK08
- 5 years guarantee
Areas of application
- Direct replacement for luminaires with fluorescent lamps
- Indoor applications
- Industrial and commercial halls
- Public areas
- Corridors, stairwells, basements
Product features
- Very high luminous efficacy: up to 125 lm/W
- Robust metal housing and PC diffuser
- Wiring at back side of luminaire
- Through wiring possible
Equipment / Accessories
- Mounting screws and dowels included
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
References / Links
- For Guarantee see www.ledvance.com/guarantee
Product identifiers
Price: £ 53.10 Excl. VAT
ETIM group
Specifications
Electrical data
| Nominal wattage | 33.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 150 mA |
| Inrush current | 20 A |
| Inrush current time T h50 | 100 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 41 |
| Max. number of luminaires per miniature circuit breaker C10 | 33 |
Documents
Documents and certificates
Data sheet
Documents And Certificates
User instruction / safety instructions – LINEAR ULTRA OUTPUT
On-Pack-Info – Legal Insert Linear LED UO
Legal information – LINEAR ULTRA OUTPUT 1200
Legal information – LS Insert Linear Ultra Output
Legal information – Informationstext 18 Abs 4 ElektroG
Declarations of conformity UKCA – LN UO 1200
Product Images And Graphics
Product image: white background, horizontal – LINEAR ULTRA OUTPUT 1200
