LED T Slim 60 320° DIM 6.5W 827 Clear E14

1 / 5

LED T Slim 60 320° DIM 6.5W 827 Clear E14

LED T Slim 60 320° DIM 6.5W 827 Clear E14 by LEDVANCE is listed by 1 electrical wholesaler on Voltimum UK, including Farnell. Trade price £14.88 excl. VAT.

Product benefits

Easy replacement of halogen lamps thanks to compact design
Ideal in particular for many small designer luminaires
Lower thermal output (compared with the standard reference product)
Three year guarantee
Lower energy consumption than incandescent or halogen lamps

Areas of application

Small designer luminaires
Wherever compact and efficient lamps are needed
Outdoor use in suitable outdoor luminaires only

Product features

Dimmable (with many common dimmers, see also www.ledvance.com/dim)
LED alternative to conventional high voltage lamps
Good quality of light; color rendering index R_a: ≥ 80; constant chromaticity

Safety advice

Do not touch the lamp if broken.
Must not be used if outer bulb is defective.
To ensure full light efficiency and product lifetime, it is recommended to detach any glass or cover of the luminaire.

References / Links

For dimming conformity see www.ledvance.com/dim
For Guarantee see www.ledvance.com/guarantee

Product identifiers

SKU: 4058075607316

EAN: 4058075607316

GTIN: 4058075607316

MPN: 4058075607316

Price: £ 14.88 Excl. VAT

Specifications

Electrical data

Nominal wattage	6.5 W
Construction wattage	6.50 W
Nominal voltage	220…240 V
Operating mode	AC Mains
Claimed equiv. conventional lamp power	60 W
Nominal current	37 mA
Type of current	AC
Inrush current	0.202 A
Operating frequency	50/60 Hz
Mains frequency	50/60 Hz
Max. lamp number on MCB B10 A	216
Max. lamp number on MCB B16 A	345
Total harmonic distortion	96.1 %
Power factor λ	> 0.50

Documents

Documents and certificates

Data sheet

Open

Documents And Certificates

Declarations of conformity UKCA – LED TSLIM

Open

Declarations of conformity UKCA – LED lamp

Open

PRODUCT DATASHEET – TSLIMDIM603207W2700KE1 4en

Open

Product datasheet -> old version of product – LEDTSlim60320°DIM7W82 7ClearE14en

Open

Product datasheet -> old version of product – LEDTSlim60320°DIM6.5W 827ClearE14en

Open

Product datasheet -> old version of product – LEDTSlim60320°DIM6.5W 827ClearE14en

Open

Product Images And Graphics

Product image: white background, diagonal with OSRAM logo – LED TSLIM 60 DIM 230V Clear E14 Plastic

Open

Product image: white background, diagonal – LED TSLIM 60 DIM 230V Clear E14 Plastic

Open

Product image: white background, upright, OSRAM logo – LED TSLIM 60 DIM 230V Clear E14 Plastic

Open

Product image: white background, upright – LED TSLIM 60 DIM 230V Clear E14 Plastic

Open

Product line drawing with letters – LED TSLIM 60 DIM 230V Clear E14 Plastic

Open

Product line drawing with numbers – LED TSLIM 60 DIM 230V Clear E14 Plastic

Open

Product line drawing - technical – LED TSLIM 60 DIM 230V Clear E14 Plastic

Open

Combo Shot = Product Beauty Shot + Packaging Image – LEDTSLIM60D CL 7W-827 230V E14 FS1 OSRAM

Open

Packaging image, frontal – LED ST SPECIAL T SLIM 60 DIM 7W 827 CL E14 MiCh

Open

Packaging image, spacial – LED ST SPECIAL T SLIM 60 DIM 7W 827 CL E14 MiCh

Open

Energy Label 2021 UK – EL-4058075607316-AC321 25

Open

Energy Label 2021 UK – EL-4058075607316-AC589 89

Open

Energy Label 2021 UK – EL-4058075607316-AC841 50

Open

Luminous flux	806 lm
Luminous efficacy	124 lm/W
Lumen main.fact.at end of nom.life time	0.93
Light color (designation)	Warm White
Color temperature	2700 K
Color rendering index Ra	80
Light color	827
Standard deviation of color matching	≤6 sdcm
Flickering metric (Pst LM)	1.0
Stroboscope effect metric (SVM)	0.4

Beam angle	320 °
Warm-up time (60 %)	‹ 0.50 s
Starting time	< 0.5 s

Overall length	82.00 mm
Diameter	20.00 mm
Maximum diameter	20 mm
Product weight	22.00 g

Ambient temperature range	-20…+40 °C
Maximum temperature at tc test point	101.4 °C

Lifespan L70/B50 at 25 °C	15000 h
Number of switching cycles	100000
Lumen maintenance at end of service lifetime	0.93

LED T Slim 60 320° DIM 6.5W 827 Clear E14

Product benefits

Areas of application

Product features

Safety advice

References / Links

Categories

ETIM group

Specifications

Documents

Base (standard designation)	E14
Mercury content	0.0 mg
Mercury-free	Yes
Design / version	Clear
Product remark	All technical parameters apply to the entire lamp; Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value

Energy efficiency class	E 1)
Energy consumption	7.00 kWh/1000h
Type of protection	IP20
Standards	CE; UKCA; EAC
Photobiological safety group acc. to EN62778	RG1

Lighting technology used	LED
Non-directional or directional	NDLS
Mains or non-mains	MLS
Light source cap-type (or other electric interface)	E14
Connected light source (CLS)	No
Color-tuneable light source	No
Envelope	No
High luminance light source	No
Anti-glare shield	No
Correlated colour temperature type	SINGLE_VALUE
Standby power	0 W
Claim of equivalent power	Yes
Length	82.00 mm
Height	20.00 mm
Width	20.00 mm
Chromaticity coordinate x	0.4578
Chromaticity coordinate y	0.4101
R9 Colour rendering index	1
Beam angle correspondence	SPHERE_360
Survival factor	0.9
Displacement factor	0.5
LED light source replaces a fluorescent light source	No
EPREL ID	522886,1877435,2365061
Model number	AC32125,AC58989,AC58989,AC84150

Minimum rate of recycled material in packaging	80 % 1)
Minimum percentage of recycled content in the product	0 % 1)
Product recyclability	Mostly recyclable product 1)
Packaging recyclability	Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
