MFT-X1 -BS + EVX100 BUNDLE

Link copied

SKU
EAN
GTIN
MPN

Automatic interface for testing EVSEs with the MFT-X1 + Multifunction electrical installation tester - 3 Phase high with high resolution "Confidence meter" loop impedance measurement, TFT display, RCD type AC, A, B, EV PRCD, Result downloading

Specifications

Interface	yes
Indication	Graphic
RCD/FI testing	yes
Printer connection	no
Printer integrated	no
Field rotation test	yes
Earthing measurement	yes
Earth loop measurement	yes
Limit value indication	yes
Testing of IMDs and RCMs	no
Low resistance measurement	yes
PRCD testing type S, type K	yes
Over voltage protector testing	no
Isolation resistance measurement	yes
Remote control for testing device	no
Loop resistance/impedance measurement	yes
Mains internal resistance measurement	yes
Loop measurement without RCD/FI release	yes
Resistances of isolating floors and walls	no
Measuring of leakage currents with adapter	yes
RCD/FI testing with rising residual current	yes
Low resistance measurement with ramp function	no
Isolation resistance measurement with ramp function	no
Detection short-circuit current/overcurrent protection	yes
Testing of charging devices E-Mobility, simulation of vehicle status	yes
