TeSys K reversing contactor - 3P - AC-3 <= 440 V 9 A - 1 NC - 48 V AC coil
1 / 2
TeSys K reversing contactor - 3P - AC-3 <= 440 V 9 A - 1 NC - 48 V AC coil
TeSys K reversing contactor - 3P - AC-3 <= 440 V 9 A - 1 NC - 48 V AC coil by Schneider Electric is listed by 3 electrical wholesalers on Voltimum UK, including Control Components Anglia, Farnell and RS Components. It is currently in stock at 1 of them. Trade prices range from £110.38 to £112.46 excl. VAT. Voltimum+ members earn 13 points per unit.
TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V). It provides 48V 50/60Hz AC coils, 2NC built-in auxiliary contacts, connection by solder pins for printed circuit board. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With mechanical interlock (without electrical interlocking), this model has no pre-wired reversing power connections. Multi standards certified (IEC, UL, CSA, CCC, EAC)
Product identifiers
SKU: LC2K09015E7
EAN: 3389110492071
GTIN: 3389110492071
MPN: LC2K09015E7
Loyalty points:
13
Price range: £ 110.38 - £ 112.46 Excl. VAT
ETIM group
Specifications
| Depth | 57 mm |
| Width | 90 mm |
| Height | 58 mm |
| Function | Reversing contactor |
| Operating voltage DC | |
| Degree of protection (IP) | IP20 |
| Operating voltage AC 50 Hz | |
| Operating voltage AC 60 Hz |
