TR LN 750 P 35W ML 840 SY120 OP WT
TR LN 750 P 35W ML 840 SY120 OP WT
Product benefits
- Highly versatile due to selectable lumen steps (Multi Lumen) on the driver
- Low flicker light thanks to special electronic control gear
- High color rendering: CRI = 80
Areas of application
- Retail
- Supermarkets
- Shops, boutiques
Product features
- Multi Lumen function: 5 lumen steps selectable
- High luminous efficacy: up to 155 lm/W
- Available beam angle: 120° symmetric (SY)
- Color temperatures: 4000 K, 3000 K (on request)
- Available in matt white (like RAL9003), matt black (like RAL9005)
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
References / Links
- For Guarantee see www.ledvance.com/guarantee
Product identifiers
Categories
Specifications
Lifespan
| Lifespan L70/B50 at 25 °C | 100000 h 1) |
| Lifespan L80/B10 at 25 °C | 100000 h 1) |
| Lifespan L90/B10 at 25 °C | 54000 h |
| Number of switching cycles | 50000 |
Control gear
| Output current | 450…400…350…300…250 mA |
| ECG - Output ripple current | < 5 % |
Electrical data
| Nominal wattage | 35 W / 31 W / 27 W / 23 W / 20 W |
| Nominal voltage | 220…240 V |
