LED Superstar Classic P 60 Filament DIM 5.9W 827 Clear E14

1 / 5

LED Superstar Classic P 60 Filament DIM 5.9W 827 Clear E14

LED Superstar Classic P 60 Filament DIM 5.9W 827 Clear E14 by LEDVANCE is listed by 2 electrical wholesalers on Voltimum UK, including Farnell and Rexel Group. It is currently in stock at 1 of them. Trade price £8.25 excl. VAT.

Product benefits

Lamps with innovative LED "filament" technology
Lower energy consumption than incandescent or halogen lamps
Instant 100 % light, no warm-up time
Can be easily fitted instead of ordinary light bulbs
Design, dimensions, luminous flux comparable to an incandescent lamp

Areas of application

Perfect for decorative installations
Domestic applications
General illumination
Outdoor use in suitable outdoor luminaires only

Product features

LED lamps for line voltage
Dimmable (with many common dimmers, see also www.ledvance.com/dim)
Beam angle: up to 300°
Lamp made of glass
Good quality of light; color rendering index R_a: ≥ 80; constant chromaticity

Safety advice

Do not touch the lamp if broken.
Must not be used if outer bulb is defective.

Product identifiers

SKU: 4058075447875

EAN: 4058075447875

GTIN: 4058075447875

MPN: 4058075447875

Price: £ 8.25 Excl. VAT

Specifications

Electrical data

Nominal wattage	5.9 W
Construction wattage	5.90 W
Nominal voltage	220…240 V
Operating mode	AC Mains
Claimed equiv. conventional lamp power	60 W
Nominal current	35 mA
Type of current	AC
Inrush current	0.5 A
Operating frequency	50/60 Hz
Mains frequency	50/60 Hz
Max. lamp number on MCB B10 A	72
Max. lamp number on MCB B16 A	115
Total harmonic distortion	≤ 110 %
Power factor λ	> 0.50

Documents

Documents and certificates

Data sheet

Open

Documents And Certificates

Declarations of conformity UKCA – LED lamp

Open

Declarations of conformity UKCA – LED lamps

Open

Declarations of conformity UKCA – LED lamp

Open

PRODUCT DATASHEET – SSTCLASP606.5W2700KE14 en

Open

Product datasheet -> old version of product – LEDSuperstarClassicP60 FilamentDIM5.5W827Clea rE14en

Open

Product datasheet -> old version of product – LEDSuperstarClassicP60 FilamentDIM5.9W827Clea rE14en

Open

Product datasheet -> old version of product – LEDSuperstarClassicP60 FilamentDIM5.9W827Clea rE14en

Open

Product Images And Graphics

Luminous flux	806 lm
Luminous efficacy	136 lm/W
Lumen main.fact.at end of nom.life time	0.96
Light color (designation)	Warm White
Color temperature	2700 K
Color rendering index Ra	80
Light color	827
Standard deviation of color matching	≤6 sdcm
Flickering metric (Pst LM)	≤1.0
Stroboscope effect metric (SVM)	≤0.4

Beam angle	300 °
Warm-up time (60 %)	‹ 0.50 s
Starting time	< 0.5 s

Overall length	80.00 mm
Diameter	45.00 mm
Maximum diameter	45 mm
Product weight	15.00 g

Ambient temperature range	-20…+40 °C
Maximum temperature at tc test point	60 °C

Lifespan L70/B50 at 25 °C	25000 h
Number of switching cycles	100000
Lumen maintenance at end of service lifetime	0.96

LED Superstar Classic P 60 Filament DIM 5.9W 827 Clear E14

Product benefits

Areas of application

Product features

Safety advice

Categories

ETIM group

Specifications

Documents

Base (standard designation)	E14
Mercury content	0.0 mg
Mercury-free	Yes
Design / version	Clear
Product remark	All technical parameters apply to the entire lamp; Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value

Energy efficiency class	D 1)
Energy consumption	6.00 kWh/1000h
Type of protection	IP20
Standards	CE; UKCA; EAC
Photobiological safety group acc. to EN62778	RG1

Lighting technology used	LED
Non-directional or directional	NDLS
Mains or non-mains	MLS
Light source cap-type (or other electric interface)	E14
Connected light source (CLS)	No
Color-tuneable light source	No
Envelope	No
High luminance light source	No
Anti-glare shield	No
Correlated colour temperature type	SINGLE_VALUE
Standby power	0 W
Claim of equivalent power	Yes
Length	80.00 mm
Height	45.00 mm
Width	45.00 mm
Chromaticity coordinate x	0.4578
Chromaticity coordinate y	0.4101
R9 Colour rendering index	1
Beam angle correspondence	SPHERE_360
Survival factor	0.90
Displacement factor	≥0.5
LED light source replaces a fluorescent light source	No
EPREL ID	1403347,523224,1373514,1838169,2178979,2521444
Model number	AC32317,AC45154,AC24256,AC57890,AC70157,AC93235

Quantity of precious metals	Contains at least 10 mg
Quantity of rare earths	Contains at least 1 mg
Minimum rate of recycled material in packaging	80 % 1)
Minimum percentage of recycled content in the product	0 % 1)
Product recyclability	Mostly recyclable product 1)
Packaging recyclability	Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
