| Width |
150 mm |
| Colour |
Grey |
| Height |
125 mm |
| Length |
3000 mm |
| Weight |
2.2633 kg/m |
| Material |
Steel |
| RAL-number |
- |
| Type of rung |
Perforated profile |
| Fixation rung |
Welded |
| Working length |
3000 mm |
| Material quality |
- |
| Side perforation |
yes |
| Surface protection |
Hot-dip galvanised |
| Type of side joist |
Profile (open) |
| Rung centre spacing |
- |
| Useful cross section |
- |
| Operating temperature |
-50 - 150 °C |
| Vertical cable ladder |
yes |
| Possible support spacing |
|
| Suitable for circuit integrity |
no |
| Load test type according to IEC 61537 |
- |
| Safe working load according to IEC 61537 with support spacing 0.5 m |
- |
| Safe working load according to IEC 61537 with support spacing 1.0 m |
- |
| Safe working load according to IEC 61537 with support spacing 1.5 m |
- |
| Safe working load according to IEC 61537 with support spacing 2.0 m |
- |
| Safe working load according to IEC 61537 with support spacing 2.5 m |
5138 N/m |
| Safe working load according to IEC 61537 with support spacing 3.0 m |
3569 N/m |
| Safe working load according to IEC 61537 with support spacing 4.0 m |
2010 N/m |
| Safe working load according to IEC 61537 with support spacing 5.0 m |
1284 N/m |
| Safe working load according to IEC 61537 with support spacing 6.0 m |
892 N/m |
| Safe working load according to IEC 61537 with support spacing 7.0 m |
- |
| Safe working load according to IEC 61537 with support spacing 8.0 m |
- |
| Safe working load according to IEC 61537 with support spacing 9.0 m |
- |
| Safe working load according to IEC 61537 with support spacing 10.0 m |
- |
| Safe working load according to IEC 61537 with support spacing 11.0 m |
- |
| Safe working load according to IEC 61537 with support spacing 12.0 m |
- |
