| Depth |
23 |
| Width |
3.5 |
| Colour |
Black |
| Height |
7.8 |
| Transparent |
no |
| Halogen free |
- |
| Rated voltage |
160 |
| Mounting method |
Other |
| Number of poles |
2 |
| Rated current In |
8 |
| Operating temperature |
-60 - 100 |
| Closing plate required |
no |
| Material insulation body |
Thermoplastic |
| Drill hole distance centrically |
- |
| Explosion-tested version 'Ex e' |
no |
| Type of electrical connection 1 |
Spring clamp connection |
| Type of electrical connection 2 |
- |
| Number of clamp positions per pole |
1 |
| Connectable conductor cross section solid-core |
0.2 - 1.5 |
| Connectable conductor cross section multi-wired |
0.2 - 1.5 |
| Inflammability class of insulation material according to UL94 |
- |
| Connectable conductor cross section fine-strand with cable end sleeve |
0.25 - 1.5 |
| Connectable conductor cross section fine-strand without cable end sleeve |
0.2 - 1.5 |
