Schneider Electric

Rectangular green complete pilot light Ø16 with integral LED 12...24V

Link copied
SKU
EAN
GTIN
MPN

Rectangular green complete pilot light Ø16 with integral LED 12...24V by Schneider Electric is listed by 2 electrical wholesalers on Voltimum UK, including Farnell and RS Components. It is currently in stock at 1 of them. Trade prices range from £14.81 to £15.56 excl. VAT. Voltimum+ members earn 2 points per unit.

"This product is part of the Harmony XB6 range, an offer of Ø 16mm plastic pushbuttons, switches, and pilot lights." "This pilot light indicates a closed or active circuit with a light." "It has a rectangular shaped head with green lens." "It is equipped with integral LED base and LED light. The light block is rated to 12V to 24V AC/DC supply voltage." "It is furnished with 2.8mm x 0.5mm Faston connector for electrical connection." "It is an IP65 and NEMA 4/4X/13 rated product." "This SK Plus options type pilot light is fitted with plastic bezel. Its dimensions are 24mm (width) x 57mm (depth) x 18mm (height). It weighs 0.015kg." "It is ideal for control boards, surveillance rooms, alarms, small finishing machines, local and remote control panels." "This product is certified by CCC, CSA, UL and GOST. It meets JIS C 852, JIS C8201-5-1, EN/IEC 60947-1, EN/IEC 60947-5-5, EN/IEC 60947-5-1 and JIS C8201-1 standards." "It is installed into a Ø 16mm panel cutout." "The modular and monolithic range of Ø 16mm plastic control and signaling provide flexibility and simplicity of setup in industrial and commercial applications."

Voltimum+ Loyalty Programme Loyalty points: 2

Price range: £ 14.81 - £ 15.56 Excl. VAT

Categories

LED Lighting LED Lighting & Luminaires LED Bulbs & Lamps

ETIM group

Low-voltage industrial components

Specifications

Colour lens Green
Type of lens Flat
Voltage type AC/DC
Hole diameter 16.2 mm
Width opening -
Height opening -
With front ring yes
Colour front ring Black
Material front ring Plastic
Construction type lens Rectangular
Number of indicator lights 1
Degree of protection (NEMA) Other

Documents

Declaration of Conformity (Sustainability)

XB6DV3BB REACh Regulation

Open

Product data sheet

Open

Catalog

Discover catalog Harmony XB6 and XB6E plastic Control and signaling units Ø 16

Open

Declaration of Conformity (Sustainability)

XB6DV3BB EU RoHS Directive

Open

Declaration of conformity

XB6A/C/D, ZB6A/C/D control and signaling units

Open

Environmental Disclosure

Harmony XB5 Pilot Light

Open

Circularity Profile

750 Series Hermetically Sealed Relay

Open

CAD

Open
