| Cable |
- |
| CE mark |
Yes |
| Dimmable |
No |
| ENEC mark |
- |
| Connection |
2 push-in connectors 3-pole |
| Optic type |
Open area or corridor optic |
| Inrush time |
100 ms |
| Input Voltage |
220-240 V |
| Luminous Flux |
273 lm |
| Glow-wire test |
- |
| Housing Colour |
White |
| Inrush current |
3.04 A |
| Line Frequency |
50 Hz |
| Optic material |
Polycarbonate |
| Overall height |
46 mm |
| Driver included |
Yes |
| Mounting device |
- |
| Warranty period |
5 years |
| Housing material |
Polycarbonate |
| Lamp family code |
- |
| Overall diameter |
155 mm |
| Control interface |
Internal (no external connection) |
| EU RoHS compliant |
Yes |
| Fixation material |
- |
| Flammability mark |
- |
| Maximum dim level |
Not applicable |
| Power Consumption |
2 W |
| Optic type outdoor |
- |
| Optical cover type |
- |
| Reflector material |
- |
| Light source colour |
6500 |
| Initial chromaticity |
0.33 |
| Protection class IEC |
Safety class II |
| Constant light output |
No |
| Ingress protection code |
IP65 | Dust penetration-protected, jet-proof |
| Luminous flux tolerance |
+/-5% |
| Power Factor (Fraction) |
0.39 |
| Effective projected area |
25 m² |
| Light source engine type |
LED |
| Ambient temperature range |
+5 to +40 °C |
| End CLO power consumption |
2 W |
| Optical cover/lens finish |
Clear |
| Upwards light output ratio |
0.0 |
| Luminaire light beam spread |
150° - 80° x 30° |
| Optical cover/lens material |
UV-stabilised polycarbonate cover |
| Power consumption tolerance |
+/-10% |
| Colour rendering index (CRI) |
<gt/>80 |
| Mech. impact protection code |
IK03 | 0.3 J |
| Standard tilt angle post-top |
0° |
| Average CLO power consumption |
2 W |
| Driver/power unit/transformer |
- |
| Initial CLO power consumption |
2 W |
| Suitable for random switching |
Not applicable |
| Luminous efficacy (rated) (nom.) |
135 lm/W |
| Correlated Colour Temperature (Nom) |
6500 K |
| Lumen maintenance (EN-IEC 62722-2-1) at median useful life* 35000 h |
L95 |
| Lumen maintenance (EN-IEC 62722-2-1) at median useful life* 50000 h |
L95 |
| Lumen maintenance (EN-IEC 62722-2-1) at median useful life* 75000 h |
L95 |
| Lumen maintenance (EN-IEC 62722-2-1) at median useful life* 100000 h |
L95 |
