The WINSTA® Pluggable Connection System easily meets the strict requirements of building installations. The system provides simple pluggable electrical connections – making electrical installation fast, safe and error-free. This is also true for other applications, such as marine and railway systems, as well as industrial applications.
The Benefits for You:
- Protected against mismating and maintenance-free
- Push-in CAGE CLAMP® spring pressure connection technology allows solid conductors to be simply pushed in
- A wide product range readily meets all electrical installation requirements: plugs, sockets, snap-in device connectors and PCB connectors, as well as distribution connectors, cable assemblies and distribution boxes
- Compact design
- Components can be clearly printed on and color-coded to meet custom requirements
Discover the diversity of the WINSTA® Pluggable Connection System
For Space-Restricted Applications: WINSTA® MINI
The WINSTA® MINI family is ideal for pluggable electrical installations in confined spaces. Its compact design supports the trend towards downsized components, including LED lights and electronic ballasts.
Your Benefits:
Conductor range: up to 1.5 mm2 (16 AWG)
Nominal current: 16 A
WINSTA® MINI special components (with custom printing) for specialty applications such as measurement, control and regulation technology
Compact pluggable PCB connectors are available with 4.4 mm pole spacing
Show product list:
For Maximum Possibilities: WINSTA® MIDI
The WINSTA® MIDI family offers the greatest diversity of components for fast, reliable, error-free electrical installation. This allows you to meet a great variety of requirements individually and flexibly.
The Benefits for You:
- Conductor range: up to 4 mm2 (12 AWG)
- Nominal current: 25 A
- Two wire connections per pole for loops or bridges
- Easily identifiable through optional customer-specific printing and intelligent marking accessories
- Additional variable coding possible
- Available in 2- to 7-pole configurations
- Pluggable lighting connection with the universal Linect® Lighting Connection System and WINSTA® Linect® T-Connector
