• Assess, track, and forecast insulation state, aiding in the analysis of risks and data-driven life extension • Improve decision-making with automated data collection and recommendations based on industry standards • Optimisation of aged transformer fleet management and replacement programmes
Schneider Electric, the leader in the digital transformation of energy management and automation, is offering a new solution that extends transformer lifetime. By incorporating digital transformation through the implementation of IoT sensors and expert analysis, Schneider Electric can now monitor transformer insulation health. The EcoStruxture Transformer Expert, designed for affordable and accurate transformer monitoring, is a game-changer with the ability to offer automated insights that identify assets of concern and recommend action.
Periodic oil sample data is collected using new sensors, which allow in data analysis and correlation with insights to predict irreversible patterns. Potential risks can thus be assessed, and data-driven life extension, risk reduction, and maintenance programmes can be developed.
The most common cause of failure of transformer is insulation failure; it deteriorates due to partial discharge, water content in oil and paper and temperature. With the average transformer cost having risen by 5.5% annually for around 20 years, equivalent to a 100% increase in the cost of a transformer every 20 years.
The EcoStruxure Transformer Expert difference
EcoStruxture™ Transformer Expert (ETE) allows users to assess, track and forecast insulation state and life left through automated online analysis. The solution offers fleetwide dashboard and configurable alerts. By using low-cost and multi-sensor probes and automated algorithms and alerts, this solution can provide an accurate state assessment through modelling and prediction.
The optimisation of transformation life
The ETE platform uses an innovative sensor to monitor transformer key parameters in order to optimise transformer life. These include:
- Engineering data: this is inclusive of temperature, water activity, PD and vibration as well as, fleetwide and individual trends to aid in forecasting.
- Operating state: this focuses on measuring the temperature and water activity. This also involves a breakdown voltage of oil and offers sage limits and trend alerts.
- Insulation aging: the new system can calculate effective age, aging rate and life left in order to prevent risk and offer maintenance strategies.
- Maintenance management: this includes features such as identifying leaks, incorporating cooling optimisation and dry-out impacts/modelling to aid with decision making.
- Asset management: In addition to measuring maintenance issues, the solution implements fleetwide replacement ranking and a scenario analysis, which forecasts the impact of load changes on temperature and life left.
The science behind EcoStruxure Transformer Expert
In three simple steps the sensor is ready to start monitoring the transformer using built-in mobile communications - meaning no network configuration. This data is then analysed, and insights are provided enabling the prediction of irreversible tendencies. Ultimately, extending the life of your transformer.
“Automated data collection, analysis and recommendations are essential components to optimising the life of your transformer”, said Lee Slaymaker, Power Services Commercial Lead at Schneider Electric. “The 3 main root causes of insulation decay can quickly and easily be monitored, with no special training required, allowing you to make an informed decision that will avoid irreversible trends”.
