PANEL COMFORT 625 AND MCU SELECT 4XPL CMFT 625 1XMCU
Reliable all-in-one solution for modern office lighting – optimized for DIRECT EASY. Product features: 4x PANEL COMFORT 625 ZIGBEE GEN 2. 1x MANUAL CONTROL UNIT SELECT DIRECT 100–240 ZB. Rotary dimmer for flush-mounted installation for manual light control. External driver with through-wiring box for flexible installation. Lifetime: up to 100,000 h (L70/B50 at 25 °C). Easy compatibility with the DIRECT EASY app. Product benefits: Complete solution expandable to up to 40 Zigbee Direct luminaires. Easy commissioning via the DIRECT EASY app using Bluetooth – no internet or user account required. High energy efficiency with up to 130 lm/W. Low maintenance requirements thanks to mains operation. Low flicker levels and seamless dimming. Areas of application: Offices. Conference rooms. Installations with 625 x 625 mm grid ceilings. Applications requiring simple, centralized lighting control. Safety advice: All electrical connections must be made by a qualified person.. If the external flexible cable or cord of this luminaire is damaged, it shall be replaced by a special cord or cord exclusively available from the manufacturer or his service agent.. Caution, risk of electric shock.. The luminaires are not suitable for covering with thermally insulated material..
Product identifiers
SKU: 4099854704161
EAN: 4099854704161
GTIN: 4099854704161
MPN: DIRECT EASY KIT 4XPL CMFT 625 1XMCU
Price: £ 0.00 Excl. VAT
Categories
Features
|
Width
|
620
|
|
Length
|
620
|
|
EFNL0014
|
false
|
|
Lamp type
|
-
|
|
Beam angle
|
Extreme wide beam >80°
|
|
Dimming RF
|
no
|
|
Dimming DMX
|
no
|
|
Dimming DSI
|
no
|
|
Lamp holder
|
-
|
|
Dimming DALI
|
no
|
|
Height/depth
|
32.00
|
|
Light outlet
|
Direct
|
|
Power factor
|
0.95
|
|
Type of grid
|
High-gloss
|
|
Voltage type
|
AC/DC
|
|
Built-in width
|
600
|
|
Dimming 0-10 V
|
no
|
|
Dimming 1-10 V
|
no
|
|
Dimming DALI-2
|
no
|
|
Dimming Zigbee
|
yes
|
|
Housing colour
|
White
|
|
Material cover
|
Plastic, opal
|
|
Outer diameter
|
-
|
|
Type of wiring
|
Suitable for loop-through wiring
|
|
With air slots
|
no
|
|
Built-in length
|
600
|
|
Colour of light
|
White
|
|
Connection type
|
Push-in clamp
|
|
Impact strength
|
IK02
|
|
No dim function
|
no
|
|
Nominal current
|
150 - 150
|
|
Nominal voltage
|
220 - 240
|
|
Number of poles
|
2
|
|
Housing material
|
Aluminium
|
|
Built-in diameter
|
-
|
|
Light distributor
|
Diffuser lens/optic/panel
|
|
Max. system power
|
33
|
|
With control gear
|
yes
|
|
With light sensor
|
no
|
|
With light source
|
yes
|
|
Colour temperature
|
4000 - 4000
|
|
Dimming LineSwitch
|
no
|
|
Light distribution
|
Symmetric
|
|
Luminaire efficacy
|
130
|
|
Luminous intensity
|
-
|
|
Dimming programmable
|
yes
|
|
Type of control gear
|
Electronic ballast
|
|
With movement sensor
|
no
|
|
Beam angle adjustable
|
No
|
|
Built-in height/depth
|
50
|
|
Dimming Touch and Dim
|
no
|
|
Operation by Bluetooth
|
no
|
|
Compatible with Casambi
|
no
|
|
Conductor cross section
|
-
|
|
Flickering value Pst LM
|
-
|
|
IFTTT support available
|
yes
|
|
Suitable for lamp power
|
|
|
Dimming with push-button
|
no
|
|
Luminous flux adjustable
|
No
|
|
Degree of protection (IP)
|
IP40
|
|
Exchangeable control gear
|
yes
|
|
Total harmonic distortion
|
-
|
|
Unified Glare Ratio (UGR)
|
19
|
|
Colour of light adjustable
|
No
|
|
Colour rendering index CRI
|
-
|
|
Suitable for wall mounting
|
no
|
|
Surface protection housing
|
Powder coating
|
|
Constant light output (CLO)
|
no
|
|
Degree of protection (NEMA)
|
-
|
|
Dimming Sine Wave Reduction
|
no
|
|
Compatible with Amazon Alexa
|
no
|
|
Stroboscope effect value SVM
|
-
|
|
Compatible with Apple HomeKit
|
no
|
|
Suitable for ceiling mounting
|
yes
|
|
Suitable for surface mounting
|
yes
|
|
Suitable for built-in mounting
|
yes
|
|
Suitable for emergency lighting
|
yes
|
|
Suitable for suspended mounting
|
yes
|
|
Compatible with Google Assistant
|
no
|
|
Dimming mains voltage modulation
|
no
|
|
Emergency power supply integrated
|
no
|
|
Rated life time L70/B50 at 25 °C
|
100000
|
|
Dimming potentiometer (integrated)
|
no
|
|
Colour consistency (McAdam ellipse)
|
SDCM3
|
|
Dimming phase cut-on (leading edge)
|
no
|
|
Suitable for number of light sources
|
-
|
|
Dimming phase cut-off (trailing edge)
|
no
|
|
Suitable for light line configuration
|
no
|
|
Protection class according to IEC 61140
|
II
|
|
Dimming manufacturer's proprietary system
|
no
|
|
Filament test according to IEC 60695-2-11
|
650 °C - 30 s
|
|
Photobiological safety according to EN 62471
|
RG0
|
|
Rated luminous flux according to IEC 62722-2-1
|
4320
|
|
Suitable for workplace according to EN 12464-1
|
yes
|
|
Rated ambient temperature according to IEC 62722-2-1
|
-10 - +50
|
|
Max. number of luminaires per miniature circuit breaker B16 (MCB)
|
55
|
|
Max. number of luminaires per miniature circuit breaker C16 (MCB)
|
55
|
|
Covering of the luminaire with thermally insulating material possible
|
no
|
|
Failure rate at median useful life of 35,000 h at 25 °C ambient (tq)
|
-
|
|
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
|
-
|
|
Failure rate at median useful life of 75,000 h at 25 °C ambient (tq)
|
-
|
|
Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq)
|
-
|
|
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
|
-
|
|
Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq)
|
-
|
|
Energy efficiency class of the light source according to EU regulation 2019/2015
|
D
|
|
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
|
no
|
