Nominal current

8 A

Width

15 mm

Height

86 mm

Depth

73 mm

Max. starting current

-

With detachable clamps

no

Drive, polarization

Polarity free

Drive, switching attitude

Mono stable

With forced-guided contacts

no

Type of switch contact

Single contact

Complete with socket

yes

Type of electric connection

Spring clamp connection

Rated control supply voltage AC 50 Hz

230 - 230 V

Rated control supply voltage AC 60 Hz

230 - 230 V

Rated control supply voltage DC

Material of contact surface

-

Voltage type (operating voltage)

-

Degree of protection (IP)

IP20

With LED indication

yes

Material contact

-

Operating voltage AC 50 Hz

Operating voltage AC 60 Hz

Operating voltage DC

Voltage type for actuating

AC

Number of contacts as normally closed contact

Number of contacts as normally open contact

Number of contacts as change-over contact

2

Material of contact insert

-

Relay technology category according to IEC 61810-7

-
