Supporting protocol for EtherCAT

-

Certified for UL hazardous location group A (acetylene)

-

Certified for UL hazardous location group B (hydrogen)

-

Certified for UL hazardous location group C (ethylene)

-

Certified for UL hazardous location group D (propane)

-

Certified for UL hazardous location group E (metal dusts)

-

Certified for UL hazardous location group F (carbonaceous dusts)

-

Certified for UL hazardous location group G (non-conductive dusts)

-

Certified for UL hazardous location class I

-

Certified for UL hazardous location class II

-

Certified for UL hazardous location class III

-

Certified for UL hazardous location division 1

-

Certified for UL hazardous location division 2

-

Width

108 mm

Model

Compact

Height

90 mm

Depth

55 mm

With display

no

Suitable for safety functions

no

Number of digital inputs

8

Number of digital outputs

4

Number of analogue inputs

2

Number of analogue outputs

2

Voltage type (supply voltage)

DC

Type of memory

RAM

Memory size

32768 kByte

Processing time (1K, binary operation)

-

Supporting protocol for LON

no

Number of HW-interfaces industrial Ethernet

2

Number of HW-interfaces RS-232

Number of HW-interfaces RS-422

Number of HW-interfaces RS-485

1

Number of HW-interfaces USB

Number of HW-interfaces parallel

Number of HW-interfaces other

With optical interface

no

Additional program memory possible

yes

Supporting protocol for TCP/IP

yes

Supporting protocol for ASI

no

Supporting protocol for PROFIBUS

no

Supporting protocol for CAN

no

Supporting protocol for INTERBUS

no

Supporting protocol for KNX

no

Supporting protocol for Modbus

yes

Supporting protocol for Data-Highway

no

Supporting protocol for DeviceNet

no

Supporting protocol for SUCONET

no

Supporting protocol for other bus systems

yes

Redundancy

no

Suitable for rail mounting

yes

Explosion safety category for gas

None

Explosion safety category for dust

None

System accessory

no

Appendant operation agent (Ex ia)

no

Appendant operation agent (Ex ib)

no

Supporting protocol for SERCOS

no

Supporting protocol for INTERBUS-Safety

no

Number of interfaces PROFINET

Number of HW-interfaces wireless

Front built-in possible

no

Rack-assembly possible

no

Wall mounting/direct mounting

no

Radio standard Bluetooth

no

Radio standard WLAN 802.11

no

IO link master

no

Number of relay outputs

Max. number of time switches

Performance level according to EN ISO 13849-1

-

Supporting protocol for AS-Interface Safety at Work

no

Supporting protocol for DeviceNet Safety

no

Supporting protocol for EtherNet/IP

yes

Supporting protocol for Foundation Fieldbus

no

Supporting protocol for PROFINET CBA

no

Supporting protocol for PROFINET IO

no

Supporting protocol for PROFIsafe

no

Supporting protocol for SafetyBUS p

no

Supply voltage AC 50 Hz

Supply voltage AC 60 Hz

Supply voltage DC

24 - 24 V

Radio standard GPRS

no

Radio standard GSM

no

Radio standard UMTS

no

Long-Term Evolution (LTE)

-

SIL according to IEC 61508

-

Supporting protocol for IEC 61850 Ethernet

yes

Supporting protocol for DNP3

yes

Supporting protocol for IEC 60870

yes
