Interface module;with solder pin;Female connector Zoomed Image
WAGO

Interface module;with solder pin;Female connector

Interface module; with solder pin; Female connector; 9-pole; Double-deck PCB terminal blocks; in mounting carrier; with shield connection; 2,50 mm²

Product details

SKU Code: 289-650

EAN Code: 4045454013196

Minimum order: 8

This product is currently unavailable in any shop. Please contact the manufacturer for information on where it can be sourced.

No Availability (0 sellers)

Technical Data

Main Features

Mounting method

DIN rail (top hat rail) 35 mm

Width

33 mm

Height

85 mm

Depth

48 mm

Rated current

2 A

Rated voltage

125 V

Number of poles

10

Type of electrical connection, field-sided

Spring clamp connection

Pollution degree

2

Type of electrical connection, control sided

D-Sub
