Technical Data
Main Features
Mounting method
DIN rail (top hat rail) 35 mm
Colour
Green/yellow
Width
7.5 mm
Height
57.3 mm
Depth
32.9 mm
Operating temperature
105 - 105 °C
Inflammability class of insulation material according to UL94
V0
Closing plate required
yes
Type of electrical connection 1
Spring clamp connection
Type of electrical connection 2
Spring clamp connection
PEN function possible
yes
Number of levels
1
Number of clamp positions per level
2
Connectable conductor cross section solid-core
1 - 10 mm²
Connectable conductor cross section fine-strand with cable end sleeve
1.5 - 6 mm²
Connectable conductor cross section fine-strand without cable end sleeve
0.5 - 10 mm²
Connectable conductor cross section multi-wired
0.5 - 6 mm²
Material insulation body
Thermoplastic
Downloads
2-conductor ground terminal block;with push-button;6 mm²;green-yellow
Product details
SKU Code: 2206-1207
EAN Code: 4055143712064
Minimum order: 50
Good Availability (5 sellers)
Availability
46 In Stock
£2.92
159 In Stock
£3.59
29 In Stock
£4.05
3 In Stock
£178.77
(unit price £3.57) Selling in packs of 50.
We currently do not have any data on product availability.
Please visit the partner's website for pricing information.
| Distributor | Availability | Price | |
|---|---|---|---|
|
|
46 In Stock | £2.92 Ex. VAT | |
|
|
159 In Stock | £3.59 Ex. VAT | |
|
|
29 In Stock | £4.05 Ex. VAT | |
|
|
3 In Stock | £178.77 Ex. VAT | (unit price £3.57) Selling in packs of 50. |
|
|
We currently do not have any data on product availability. | Please visit the partner's website for pricing information. |
Price Range:
£2.92 > £178.77 ex. vat
