Technical Data
Main Features
Mounting method
DIN rail (top hat rail) 35 mm
Colour
Grey
Width
6.2 mm
Height
66.1 mm
Depth
57.2 mm
Rated voltage
250 V
Operating temperature
105 - 105 °C
Inflammability class of insulation material according to UL94
V0
Closing plate required
no
Type of electrical connection 1
Spring clamp connection
Type of electrical connection 2
Spring clamp connection
Type of fuse insert
G-fuse 5x20 mm
Type of fuse holder
Swivelling
Type of indication element for defect indication
None
Supply voltage for defect-indication
Number of levels
1
Voltage type for defect indication
-
Connectable conductor cross section solid-core
0.75 - 4 mm²
Connectable conductor cross section fine-strand with cable end sleeve
0.75 - 2.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve
0.25 - 4 mm²
Connectable conductor cross section multi-wired
0.25 - 2.5 mm²
Material insulation body
Thermoplastic
Rated current In
6.3 A
Downloads
2-conductor fuse terminal block;with pivoting fuse holder;and end plate;gray
Product details
SKU Code: 2002-1611
EAN Code: 4055143870344
Minimum order: 50
Good Availability (3 sellers)
Availability
251 In Stock
£4.69
307 In Stock
£5.53
420 In Stock
£47.37
(unit price £4.73) Selling in packs of 10.
| Distributor | Availability | Price | |
|---|---|---|---|
|
|
251 In Stock | £4.69 Ex. VAT | |
|
|
307 In Stock | £5.53 Ex. VAT | |
|
|
420 In Stock | £47.37 Ex. VAT | (unit price £4.73) Selling in packs of 10. |
Price Range:
£4.69 > £47.37 ex. vat
