Technical Data
Main Features
Mounting method
DIN rail (top hat rail) 35 mm
Colour
Grey
Width
6 mm
Height
38 mm
Depth
24.5 mm
Rated voltage
800 V
Operating temperature
105 - 105 °C
Inflammability class of insulation material according to UL94
V0
Closing plate required
yes
Type of electrical connection 1
Spring clamp connection
Type of electrical connection 2
Spring clamp connection
Number of levels
1
Number of clamp positions per level
2
Internally connected stages
no
Connectable conductor cross section solid-core
0.08 - 2.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve
0.25 - 1.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve
0.08 - 2.5 mm²
Connectable conductor cross section multi-wired
0.08 - 2.5 mm²
Material insulation body
Thermoplastic
Rated current In
24 A
Explosion-tested version 'Ex e'
no
Suitable for conductor material
-
Downloads
2-conductor miniature through terminal block;2.5 mm²;with test option;gray
Product details
SKU Code: 264-711
EAN Code: 4044918415415
Minimum order: 100
Good Availability (2 sellers)
Availability
95 In Stock
£0.77
(unit price £0.15) Selling in packs of 5.
669 In Stock
£0.85
| Distributor | Availability | Price | |
|---|---|---|---|
|
|
95 In Stock | £0.77 Ex. VAT | (unit price £0.15) Selling in packs of 5. |
|
|
669 In Stock | £0.85 Ex. VAT |
Price Range:
£0.77 > £0.85 ex. vat
