Width

6 mm

Height

94 mm

Depth

97.8 mm

Built-in height

-

Power consumption

-

Built-in width

-

Modular version

no

Suitable for safety functions

no

Width in number of modular spacings

0.33

Voltage type (supply voltage)

DC

Power output

2.5 W

Output voltage stabilized

no

Type of electric connection

Spring clamp connection

Suitable for rail mounting

yes

Wall mounting possible

no

Stabilized

yes

Degree of protection (IP)

IP20

Direct mounting possible

no

1st secondary output voltage

5 - 5 V

2nd secondary output voltage

3rd secondary output voltage

Secondary voltage adjustable

no

Rated supply voltage AC 50 Hz

Rated supply voltage AC 60 Hz

Rated supply voltage DC

10 - 30 V

Short-circuit-proof

yes

Performance level according to EN ISO 13849-1

-

Max. output current 1

0.5 A

Max. output current 2

-

Max. output current 3

-

Nominal value output voltage 1

5 V

Nominal value output voltage 2

-

Nominal value output voltage 3

-

Nominal value output current 1

0.5 A

Nominal value output current 2

-

Nominal value output current 3

-

SIL according to IEC 61508

-

Degree of protection (NEMA)

-
