Protection class according to IEC 61140

I

Width

137 mm

Outer diameter

-

Reflector

Other

Lamp holder

Other

Conductor cross section

1 mm²

Connection type

Other

Housing colour

Black

Surface protection

Powder coating

Voltage type

AC

With movement sensor

yes

Suitable for lamp power

Type of control gear

LED operating device current-controlled

Colour rendering index CRI

80-89

Suitable for wall mounting

yes

Built-in width

-

With light sensor

no

Suitable for suspended mounting

no

Luminous intensity

-

Number of poles

3

Length

107 mm

Height/depth

58 mm

Housing material

Aluminium

Lamp type

LED not exchangeable

Reflector colour

White

Built-in length

-

Light outlet

Direct

Light distribution

Symmetric

Material cover

Glass matt/satinized

Impact strength

IK05

Nominal voltage

220 - 240 V

Emergency power supply integrated

no

Degree of protection (IP)

IP65

With light source

yes

Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24

no

Covering of the luminaire with thermally insulating material possible

no

Suitable for number of light sources

-

Suitable for built-in mounting

no

With control gear

yes

Suitable for workplace according to EN 12464-1

no

Suitable for surface mounting

yes

Beam angle

Extreme wide beam >80°

Connectable conductor cross section

1 - 1 mm²

Surface brushed

no

Nominal current

45 - 41 mA

Colour temperature

4000 - 4000 K

Max. system power

10 W

Rated luminous flux according to IEC 62722-2-1

850 lm

Colour of light

White

Adjustability

Rotatable

Suitable for traverse mounting

no

Suitable for pedestal/floor mounting

yes

Suitable for light-track mounting

no

Suitable for clamp-mounting

no

Constant light output (CLO)

no

IFTTT support available

no

Luminous flux

850 - 850 lm

Type of wiring

Ending

Rated life time L70/B50 at 25 °C

20000 h

Colour consistency (McAdam ellipse)

SDCM6

Total harmonic distortion

20

Photobiological safety according to EN 62471

RG1

Degree of protection (NEMA)

-

Rated ambient temperature according to IEC 62722-2-1

25 - 25 °C

Filament test according to IEC 60695-2-11

650 °C - 30 s

Dimming 0-10 V

no

Dimming 1-10 V

no

Dimming DALI

no

Dimming DMX

no

Dimming potentiometer (integrated)

no

Dimming LineSwitch

no

Dimming manufacturer's proprietary system

no

Dimming mains voltage modulation

no

Dimming phase cut-off (trailing edge)

no

Dimming phase cut-on (leading edge)

no

Dimming programmable

no

Dimming RF

no

Dimming Sine Wave Reduction

no

Dimming Touch and Dim

no

Dimming Zigbee

no

Dimming with push-button

no

No dim function

yes

Light distributor

Reflector

Luminaire efficacy

85 lm/W

Suitable for low voltage cable system

no

Dimming DSI

no

Unified Glare Ratio (UGR)

-

Operation by Bluetooth

no

Suitable for ceiling mounting

no

Built-in height/depth

-

Power factor

0.9

Compatible with Apple HomeKit

no

Compatible with Google Assistant

no

Compatible with Amazon Alexa

no

Max. number of luminaires per miniature circuit breaker C16 (MCB)

256

Max. number of luminaires per miniature circuit breaker B16 (MCB)

218

Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq)

65 %

Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)

-

Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq)

-

Failure rate at median useful life of 35,000 h at 25 °C ambient (tq)

7.5 %

Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)

-

Failure rate at median useful life of 100,000 h at 25 °C ambient (tq)

-

Dimming DALI-2

no

Flickering value Pst LM

1

Stroboscope effect value SVM

-

Colour of light adjustable

No

Luminous flux adjustable

No

Beam angle adjustable

No

Exchangeable control gear

no

Built-in diameter

Energy efficiency class of the light source according to EU regulation 2019/2015

F
