Power cable 3m shielded 4x 0,82mm², BCH2 leads connection
Power cable 3m shielded 4x 0,82mm², BCH2 leads connection
Power cable 3m shielded 4x 0,82mm², BCH2 leads connection by Schneider Electric is listed by 2 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd and RS Components. It is currently in stock at all of them. Trade prices range from £31.63 to £36.93 excl. VAT. Voltimum+ members earn 5 points per unit.
"This product is part of the Lexium 28 range, an offer of motion servo drives and servo motors." "This is a shielded power cordset for BCH2 motors without brake." "It is equipped with a Molex 4-pin connector (servo motor side) and an open end (servo drive side)." "The power cable's shield serves as electromagnetic compatibility protection." "the AWG gauge of the cable is 4x AWG 18." "It measures 3m long and weighs 0.3kg." "It is a connection accessory to the BCH2 servo motors." "It is compatible with servo motors type BCH2MBA53, /MB013, /LD023, /LD043, /LF043, /HF073, /LF073." "It plugs into the power connector of BCH2 servo motors." "Lexium 28 servo drives and Lexium BCH2 servo motors are Optimized servo bundles for compact machines." "Designed for optimized & cost-effective."
Product identifiers
SKU: VW3M5D1AR30
EAN: 3606480735653
GTIN: 3606480735653
MPN: VW3M5D1AR30
Loyalty points:
5
Price range: £ 31.63 - £ 36.93 Excl. VAT
ETIM group
Specifications
| Length | 3 m |
| Frequency | |
| Connection 1 | Other |
| Connection 2 | Other |
| Nominal current | - |
| Nominal voltage | |
| Number of cores | - |
| Spiralized cable | no |
