Energy meter '15', 3-phase, 65 A

Energy meter '15', 3-phase, 65 A

D13 15 65 is a three phase energy meter, direct connection up to 65 A, four quadrant metering, class 1 accuracy for active energy according to IEC 62053-21 and class 2 for reactive energy according to IEC 62053-23, one digital input and one digital output, only three DIN module in width and housing in recycled plastic.

Product identifiers

SKU: 2CMA241725R1000
EAN: 8012542636052
GTIN: 8012542636052
MPN: D13 15 65

Voltimum+ Loyalty Programme Loyalty points: 19

Price: £ 185.16 Excl. VAT

Specifications

Depth 65
Model Direct measurement
Width 52.5
Height 97
Approval -
Frequency
Pole type Four conductor
Calibrated -
Pulse type S0
Tariff type Multi-tariff
Suitable for -
Accuracy class B
With lock code yes
Mounting method DRA (DIN-rail adapter)
Type of interface Other
Max. current (Imax) 65
Nominal current (In) 65
Nominal voltage (Un) N-L
Degree of protection (NEMA) -
Number of positions total (counter) 7
