Optocoupler module Nominal input voltage: 24 VDC Output voltage range: 3 … 30 VDC gray
Optocoupler module; Nominal input voltage: 24 VDC; Output voltage range: 3 … 30 VDC; Limiting continuous current: 0.1 A; 2-wire connection; Railway; Frequency: 10 kHz; Red status indicator; Module width: 6 mm; gray
Product identifiers
SKU: 859-796
EAN: 4055143606479
GTIN: 4055143606479
MPN: 859-796
Loyalty points:
4
Price: £ 215.50 Excl. VAT
Categories
Features
|
Input voltage
|
16.8 - 30
|
|
Output voltage
|
3 - 30
|
|
With LED indication
|
yes
|
|
Type of digital output
|
Electronic
|
|
Type of output voltage
|
DC
|
|
Rated operation current Ie
|
0.1
|
|
Type of voltage (input voltage)
|
DC
|
