Single contact block for head Ø16 1NC pins for PCB
Single contact block for head Ø16 1NC pins for PCB
Single contact block for head Ø16 1NC pins for PCB by Schneider Electric is listed by 2 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd and Farnell. It is currently in stock at 1 of them. Trade prices range from £3.21 to £5.59 excl. VAT. Voltimum+ members earn 1 point per unit.
This Harmony ZB6E2A is a single contact block for head, 1 NC with pins for PCB. It is part of the range Harmony XB6 diameter 16mm monolithic plastic push buttons, switches, and pilot lights.
Product identifiers
SKU: ZB6E2A
EAN: 3389110775297
GTIN: 3389110775297
MPN: ZB6E2A
Loyalty points:
1
Price range: £ 3.21 - £ 5.59 Excl. VAT
ETIM group
Specifications
| Model | Integrable |
| Lamp holder | None |
| Mounting method | Side mounting |
| Type of electric connection | PCB connection |
| Number of fault-signal switches | 0 |
| Number of contacts as change-over contact | 0 |
| Rated operation current Ie at AC-15, 230 V | 1.5 A |
| Number of contacts as normally open contact | 0 |
