Emergency stop head, switching off, plastic, red mushroom Ø40, Ø22, trigger and latching turn to release

Link copied

SKU
EAN
GTIN
MPN

Emergency stop head, switching off, plastic, red mushroom Ø40, Ø22, trigger and latching turn to release by Schneider Electric is listed by 7 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, Control Components Anglia, Farnell and 4 more. It is currently in stock at all of them. Trade prices range from £14.19 to £23.01 excl. VAT. Voltimum+ members earn 3 points per unit.

This Harmony XB5, Emergency stop 40mm mushroom red button head operates with a turn to release mechanism. This emergency stop / shutdown button head, is easily combined with contact blocks and installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance thanks to a clear color and a prominent 40mm mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K. It has a plastic bezel, this makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.

Loyalty points: 3

Price range: £ 14.19 - £ 23.01 Excl. VAT

ETIM group

Low-voltage industrial components

Specifications

Diameter cap	40 mm
Colour button	Red
Hole diameter	22.5 mm
Spring-return	no
Width opening	-
With lighting	no
Height opening	-
Type of button	High
With front ring	yes
Unlocking method	Turn-release
Colour front ring	Black
Material front ring	Plastic
Supply voltage lamp	-
Suitable for lighting	no
Construction type lens	Round
Degree of protection (IP)	IP66
Degree of protection (NEMA)	Other
Suitable for emergency stop	yes
Switching function latching	yes

Documents

Declaration of Conformity (Sustainability)

ZB5AS844 REACh Regulation
