P25M - circuit breaker - P25M - 3P - 1A - curve
This Acti9 P25M is a low voltage motor circuit breaker. It is a 3P circuit breaker with 3 protected poles, 1A rated current and K tripping curve. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker combines functions of circuit protection against short circuit and overload current, control and isolation. The motor protection cicuit breaker Acti9 P25M is designed for installation in modular final distribution enclosures. The Ue operational voltage is 440VAC. The Ui rated insulation voltage is 690VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 5 pitches of 9mm. The dimensions are (W) 45mm x (H) 89mm x (D) 70mm. The weight is 0.26kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -20°C to 60°C. The storage temperature is -40°C to 80°C.
Product identifiers
SKU: 21104
EAN: 3303430211044
GTIN: 3303430211044
MPN: 21104
Loyalty points:
58
Price: £ 153.70 Excl. VAT
Categories
Features
|
Frequency
|
|
|
Power loss
|
2.5 W
|
|
Voltage type
|
AC
|
|
Rated current
|
1 A
|
|
Rated voltage
|
400 V
|
|
Built-in depth
|
44 mm
|
|
Explosion-proof
|
FALSE
|
|
Pollution degree
|
3
|
|
Over voltage category
|
3
|
|
Current limiting class
|
-
|
|
Release characteristic
|
K
|
|
Number of poles (total)
|
3
|
|
Degree of protection (IP)
|
IP20
|
|
Number of protected poles
|
3
|
|
Flush-mounted installation
|
FALSE
|
|
Rated insulation voltage Ui
|
690 V
|
|
Additional equipment possible
|
TRUE
|
|
Width in number of modular spacings
|
2.5
|
|
Ambient temperature during operating
|
|
|
Rated impulse withstand voltage Uimp
|
6 kV
|
|
Concurrently switching neutral conductor
|
FALSE
|
|
Connectable conductor cross section solid-core
|
|
|
Connectable conductor cross section multi-wired
|
|
|
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
|
-
|
|
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
|
-
|
|
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
|
100 kA
|
|
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
|
100 kA
|
