TeSys K contactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 400 V AC coil
1 / 2
TeSys K contactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 400 V AC coil
TeSys K contactor - 3P - AC-3 <= 440 V 12 A - 1 NO aux. - 400 V AC coil by Schneider Electric is listed by 3 electrical wholesalers on Voltimum UK, including Control Components Anglia, Farnell and RS Components. It is currently in stock at 1 of them. Trade prices range from £42.79 to £43.22 excl. VAT. Voltimum+ members earn 5 points per unit.
TeSys K contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V), and for non-inductive load control applications up to 20A/690V AC-1. It provides a 400V 50/60Hz AC coil, 1NO built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC).
Product identifiers
SKU: LC1K1210V7
EAN: 3389110856927
GTIN: 3389110856927
MPN: LC1K1210V7
Loyalty points:
5
Price range: £ 42.79 - £ 43.22 Excl. VAT
ETIM group
Specifications
| Depth | 57 mm |
| Width | 45 mm |
| Height | 58 mm |
| Modular version | no |
| Operating voltage AC 50 Hz | |
| Operating voltage AC 60 Hz | |
| Rated operation power NEMA | - |
| Voltage type for actuating | AC |
