ClimaSys PTC heating resistance 20W, 12-24V insulate
ClimaSys PTC heating resistance 20W, 12-24V insulate by Schneider Electric is listed by 2 electrical wholesalers on Voltimum UK, including Control Components Anglia and RS Components. It is currently in stock at 1 of them. Trade prices range from £53.69 to £66.61 excl. VAT. Voltimum+ members earn 7 points per unit.
ClimaSys PTC heating resistance insulate. 20W, 12-24V DC. (-40 to 70)°C temp for operation. Electrical connection is 4 screw terminals 2.5 mm². 35 mm DIN rail mounting support. Extruded aluminium body. IP20, Insulation Class II. Electrical protection needed, must be installed with a thermal controller.
Product identifiers
SKU: NSYCR20WU1C
EAN: 3606480152269
GTIN: 3606480152269
MPN: NSYCR20WU1C
Loyalty points:
7
Price range: £ 53.69 - £ 66.61 Excl. VAT
Categories
ETIM group
Specifications
| Depth | 75 mm |
| Width | 38 mm |
| Height | 98 mm |
| With fan | no |
| Rated power | 20 W |
| Voltage type | DC |
| Operating voltage DC | |
| Degree of protection (IP) | IP20 |
