Acti9 - iKQ RCD - 4P - 80A - 30mA

Link copied
SKU
EAN
GTIN
MPN

3x points on the Schneider Electric KQ range

Acti9 - iKQ RCD - 4P - 80A - 30mA by Schneider Electric is listed by 2 electrical wholesalers on Voltimum UK, including Rexel Group and City Electrical Factors. It is currently in stock at all of them. Trade price £315.05 excl. VAT. Voltimum+ members earn 83 points per unit.

This product is a iKQ residual current circuit breaker (RCCB). Other RCCB options available This product protects against electrical shock by direct or indirect contact and fire hazards. This product is compliant with BS EN 61008 standard. The Ue operational voltage is 400VAC. The frequency is 50Hz or 60Hz. It is DIN rail mountable. The width in 9mm pitches is 8. The dimensions are (W) 72mm x (H) 81mm x (D) 75mm. The weight is 0.5kg. It has an IP20 degree of protection (as per IEC/EN 60529 standard) and becomes IP40 once in modular enclosure.

Voltimum+ Loyalty Programme Loyalty points: 249

Price: £ 315.05 Excl. VAT

Specifications

Frequency 50/60 Hz
Power loss 5.6 W
Voltage type AC
Rated current 80 A
Rated voltage 400 V
Built-in depth 44 mm
Explosion-proof no
Mounting method DIN rail
Pollution degree 2
Leakage current type AC
Selective protection no
With interlocking device no
Rated insulation voltage Ui 500 V
Additional equipment possible yes
Ambient temperature during operating
Short-circuit breaking capacity (Icw) -
Connectable conductor cross section multi-wired
