| Depth |
55.5 mm |
| Width |
27 mm |
| Height |
56 mm |
| Interface |
no |
| Mounting method |
DIN-rail/screw |
| With LED indication |
no |
| Operating voltage DC |
|
| Rated switch current |
0.005 A |
| Rated operation current |
10 A |
| Operating voltage AC 50 Hz |
|
| Operating voltage AC 60 Hz |
|
| Voltage type for actuating |
AC |
| Suitable for manual operation |
no |
| Rated control supply voltage DC |
|
| Voltage type (operating voltage) |
AC |
| Connection type auxiliary circuit |
Screw connection |
| Rated operation current Ie, 400 V |
10 A |
| Rated control supply voltage AC 50 Hz |
|
| Rated control supply voltage AC 60 Hz |
|
| Number of auxiliary contacts as change-over contact |
0 |
| Number of auxiliary contacts as normally open contact |
1 |
| Number of auxiliary contacts as normally closed contact |
1 |
| Number of auxiliary contacts as normally open contact, leading |
0 |
| Number of auxiliary contacts as normally closed contact, delayed switching |
0 |
