PCB for self-assembly with 8 mounting positions

Name: PCB for self-assembly with 8 mounting positions
Brand: Wago
SKU: 289-102
Price: 18.22 GBP
Availability: OutOfStock

PCB for self-assembly; with 8 mounting positions; 2,50 mm²

Product identifiers

SKU: 289-102

EAN: 4045454192754

GTIN: 4045454192754

MPN: 289-102

Price: £ 18.22 Excl. VAT

Terminal blocks

Specifications

Depth	31.5
Width	42.5
Colour	Other
Height	65.5
EFNA0008	V0
Rated voltage	250
Mounting method	Other
Number of levels	1
Rated current In	3
Type of component	Diode
Operating temperature	-25 - 40
Closing plate required	yes
Material insulation body	Thermoplastic
Internally connected stages	no
Explosion-tested version 'Ex e'	no
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Number of clamp positions per level	8
Connectable conductor cross section solid-core	0.08 - 2.5
Connectable conductor cross section multi-wired	0.08 - 2.5
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 1.5
Connectable conductor cross section fine-strand without cable end sleeve	0.08 - 2.5
