Trip unit TM100D for ComPacT NSX 100/160/250 circuit breakers, thermal magnetic, rating 100 A, 3 poles 3d

Link copied
SKU
EAN
GTIN
MPN

Trip unit TM100D for ComPacT NSX 100/160/250 circuit breakers, thermal magnetic, rating 100 A, 3 poles 3d by Schneider Electric is listed by 5 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, RS Components, Rexel Group and 2 more. It is currently in stock at all of them. Trade prices range from £94.83 to £184.60 excl. VAT. Voltimum+ members earn 16 points per unit.

This TM100D is a 3 poles 3d thermal-magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 100A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Voltimum+ Loyalty Programme Loyalty points: 16

Price range: £ 94.83 - £ 184.60 Excl. VAT

Specifications

Depth 88.2 mm
Width 104.7 mm
Height 60.6 mm
Number of poles 3
Supply voltage DC
Operating voltage DC
Rated switch current 100 A
Supply voltage AC 50 Hz
Type of motor protection Thermal/magnetic release
Operating voltage AC 60 Hz
Voltage type (supply voltage) -
Short-circuit release function Undelayed
Voltage type (operating voltage) AC
Current setting delayed short-circuit release
Number of auxiliary contacts as change-over contact 0
Number of auxiliary contacts as normally closed contact 0

Documents

Declaration of Conformity (Sustainability)

C103TM100 REACh Regulation

Open

User guide

ComPacT NSX - Circuit Breakers and Switch-Disconnectors 100-630 A - User Guide

Open

Instruction sheet

ComPacT NSX100-250 - TM-D/TM-G/MA/NA/DC Trip Units - Instruction Sheet

Open

Product data sheet

Open

Catalog

ComPacT NSX & NSXm Circut Breakers and Switch Disconnectors from 16 to 630A up to 690V

Open

Declaration of Conformity (Sustainability)

C103TM100 EU RoHS Directive

Open

Declaration of conformity

UK_DoC_ PB21100101B-UK_ComPacT-NSX100, 160, 250 type B, F, N, H, S, L with MA or TMD trip units

Open

Environmental Disclosure

Circuit breaker, ComPacT NSX250F, 36kA/415VAC, 3 poles, TMD trip unit 250A - Product Environmental Profile
