Mureva BOX - junction box - 8 grommets Ø 20 - 105x65x55 mm

Link copied
SKU
EAN
GTIN
MPN

Mureva BOX - junction box - 8 grommets Ø 20 - 105x65x55 mm by Schneider Electric is listed by 1 electrical wholesaler on Voltimum UK, including RS Components, and currently in stock. Trade price £3.35 excl. VAT. Voltimum+ members earn 1 point per unit.

Surface mounted junction box 105 x 65 x 55 with 8 grommets (diameter 20 mm) and clipped-on cover, Grey Degree of protection IP55, mechanical protection IK07, flame resistance 650 °C Material: ABS (body), PP (cover)

Voltimum+ Loyalty Programme Loyalty points: 1

Price: £ 3.35 Excl. VAT

Specifications

Depth 61 mm
Model Junction box
Shape Rectangular
Width 82 mm
Colour Grey
Length 125 mm
Castable no
Diameter -
Sealable no
Cover model Blind cover
Weatherproof yes
With screening no
Mounting method Wall-/ceiling mounting
For Ex-zone dust None
Circuit integrity None
Transparent cover no
Inlet from the rear no
Mounting under water no
Explosion-tested version no
Degree of protection (IP) IP55
Rated insulation voltage Ui -
Type of housing feed-through Seal membrane

Documents

Declaration of Conformity (Sustainability)

ENN05003 REACh Regulation

Open

Product data sheet

Open

Catalog

installation materials

Open

Declaration of Conformity (Sustainability)

ENN05003 EU RoHS Directive

Open

Declaration of conformity

EU Declaration of Conformity Schneider Electric

Open

Environmental Disclosure

Mureva BOX - junction box - 7 grommets Ø20 - 80x80x45 mm - Product Environmental Profile

Open
