Trip unit MA100 for ComPacT NSX 100/160/250 circuit breakers, magnetic, rating 100 A, 3 poles 3d
Schneider Electric

Trip unit MA100 for ComPacT NSX 100/160/250 circuit breakers, magnetic, rating 100 A, 3 poles 3d

This MA100 is a 3 poles 3d magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 100A rating magnetic trip unit is an optimum choice for motor protection applications. It embeds an adjustable instantaneous magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.

Product identifiers

SKU: C103MA100
EAN: 3606482000353
GTIN: 3606482000353
MPN: C103MA100

V+ Loyalty points:

40

Price range: £ 75.20 - £ 79.33 Excl. VAT

Categories

MCBs Switchgear Low Voltage Switchgear Switchgear & Circuit Protection Circuit Breakers

Videos

Promotional video

Specifications

Depth 88.2 mm
Width 104.7 mm
Height 60.6 mm
Number of poles 3
Supply voltage DC
Operating voltage DC
Rated switch current 100 A
Supply voltage AC 50 Hz
Type of motor protection Other
Operating voltage AC 60 Hz
Voltage type (supply voltage) -
Short-circuit release function Undelayed
Voltage type (operating voltage) AC
Current setting delayed short-circuit release
Number of auxiliary contacts as change-over contact 0
Number of auxiliary contacts as normally closed contact 0
