Thermal magnetic circuit breaker, TeSys GB2, 2P, 4 A, Icu 3 kA@415 V
Thermal magnetic circuit breaker, TeSys GB2, 2P, 4 A, Icu 3 kA@415 V
Thermal magnetic circuit breaker, TeSys GB2, 2P, 4 A, Icu 3 kA@415 V by Schneider Electric is listed by 6 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, Control Components Anglia, Farnell and 3 more. It is currently in stock at 4 of them. Trade prices range from £40.60 to £83.05 excl. VAT. Voltimum+ members earn 7 points per unit.
TeSys GB circuit breaker, 2 poles (2P), 4A/415V, for the protection of industrial equipment control circuits. It provides thermal magnetic protection with a magnetic tripping level at 52A (13 In) and breaking capacity Icu 3kA@415V. It can also be used for protection of DC loads up to 4A/48V DC-13 with a breaking capacity Icu 1.5kA@24V. Compact device (30mm wide), mounting on 35mm DIN-rail, control by toggle lever (start-stop guaranteed for 8000 cycles). Sold in lots of 3 units. It conforms to IEC 60947-1 and IEC 60947-2.
Product identifiers
SKU: GB2DB09
EAN: 3389110865479
GTIN: 3389110865479
MPN: GB2DB09
Loyalty points:
7
Price range: £ 40.60 - £ 83.05 Excl. VAT
Categories
ETIM group
Specifications
| Frequency | |
| Power loss | - |
| Voltage type | AC |
| Rated current | 4 A |
| Rated voltage | 415 V |
| Built-in depth | 78 mm |
| Explosion-proof | no |
| Pollution degree | 2 |
