PCB terminal block lever 4 mm² gray

Name: PCB terminal block lever 4 mm² gray
Brand: Wago
SKU: 2604-1304
Availability: InStock

PCB terminal block; lever; 4 mm²; Pin spacing 7.5 mm; 4-pole; Push-in CAGE CLAMP®; gray

Product identifiers

SKU: 2604-1304

EAN: 4066966388824

GTIN: 4066966388824

MPN: 2604-1304

Loyalty points: 4 (x70)

Price: £ 4.18 Excl. VAT

Connectors

Specifications

Height	16.7
EFNA0008	V0
Length pin	4
Rated voltage	1000
Housing colour	Grey
Type of banding	None
Number of levels	1
Pollution degree	2
Rated current In	32
Type of fastening	Solder
Connection type PCB	Soldering connection
Rated surge voltage	6
Operating temperature	-60 - 105
Over voltage category	III
Type of PCB fastening	Connecting contact
Diameter connection pin	-
Material insulation body	Thermoplastic
Connection type conductor	Spring clamp connection
Material connection surface	Tin
Modular spacing connections	7.5
RAL-number (similar) housing	-
Angle PCB/conductor connection	0°/180° (horizontal)
Number of electrical connections	4
Degree of protection (IP), mounted	-
Connectable conductor cross section solid-core	0.2 - 4
Connectable conductor cross section multi-wired	0.2 - 4
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 2.5
Connectable conductor cross section fine-strand without cable end sleeve	0.2 - 4
