Features
|
Depth
|
67.8
|
|
Width
|
24
|
|
Height
|
100
|
|
IO link master
|
no
|
|
Input, current
|
yes
|
|
Input, voltage
|
no
|
|
Input, resistor
|
no
|
|
Output, current
|
no
|
|
Output, voltage
|
no
|
|
System accessory
|
yes
|
|
Power consumption
|
-
|
|
Supply voltage DC
|
24 - 24
|
|
Radio standard GSM
|
no
|
|
Input, thermocouple
|
no
|
|
Radio standard GPRS
|
no
|
|
Radio standard UMTS
|
no
|
|
Rack-assembly possible
|
no
|
|
Front built-in possible
|
no
|
|
Supply voltage AC 50 Hz
|
|
|
Supply voltage AC 60 Hz
|
|
|
Radio standard Bluetooth
|
no
|
|
Degree of protection (IP)
|
IP20
|
|
Number of analogue inputs
|
0
|
|
Input signal, configurable
|
no
|
|
Number of analogue outputs
|
4
|
|
Output signal configurable
|
no
|
|
Radio standard WLAN 802.11
|
no
|
|
SIL according to IEC 61508
|
-
|
|
Suitable for rail mounting
|
yes
|
|
Degree of protection (NEMA)
|
-
|
|
Number of HW-interfaces USB
|
0
|
|
Supporting protocol for ASI
|
no
|
|
Supporting protocol for CAN
|
no
|
|
Supporting protocol for KNX
|
no
|
|
Supporting protocol for LON
|
no
|
|
Type of electric connection
|
Spring clamp connection
|
|
Analogue inputs configurable
|
no
|
|
Analogue outputs configurable
|
no
|
|
Input, resistance thermometer
|
no
|
|
Number of HW-interfaces other
|
0
|
|
Number of interfaces PROFINET
|
0
|
|
Suitable for safety functions
|
no
|
|
Voltage type (supply voltage)
|
DC
|
|
Wall mounting/direct mounting
|
no
|
|
Number of HW-interfaces RS-232
|
0
|
|
Number of HW-interfaces RS-422
|
0
|
|
Number of HW-interfaces RS-485
|
0
|
|
Supporting protocol for Modbus
|
no
|
|
Supporting protocol for SERCOS
|
no
|
|
Supporting protocol for TCP/IP
|
no
|
|
Supporting protocol for SUCONET
|
no
|
|
Number of HW-interfaces parallel
|
0
|
|
Number of HW-interfaces wireless
|
0
|
|
Supporting protocol for EtherCAT
|
-
|
|
Supporting protocol for INTERBUS
|
no
|
|
Supporting protocol for PROFIBUS
|
no
|
|
Appendant operation agent (Ex ia)
|
yes
|
|
Appendant operation agent (Ex ib)
|
yes
|
|
Explosion safety category for gas
|
ATEX gas-ex-protection, Cat. 3G
|
|
Resolution of the analogue inputs
|
12
|
|
Supporting protocol for DeviceNet
|
no
|
|
Supporting protocol for PROFIsafe
|
no
|
|
Explosion safety category for dust
|
ATEX dust-ex-protection, Cat. 3D
|
|
Number of HW-interfaces serial TTY
|
0
|
|
Resolution of the analogue outputs
|
-
|
|
Supporting protocol for EtherNet/IP
|
no
|
|
Supporting protocol for PROFINET IO
|
no
|
|
Supporting protocol for SafetyBUS p
|
no
|
|
Supporting protocol for Data-Highway
|
no
|
|
Supporting protocol for PROFINET CBA
|
no
|
|
Supporting protocol for INTERBUS-Safety
|
no
|
|
Supporting protocol for DeviceNet Safety
|
no
|
|
Supporting protocol for other bus systems
|
no
|
|
Certified for UL hazardous location class I
|
-
|
|
Number of HW-interfaces industrial Ethernet
|
0
|
|
Supporting protocol for Foundation Fieldbus
|
no
|
|
Certified for UL hazardous location class II
|
-
|
|
Certified for UL hazardous location class III
|
-
|
|
Performance level according to EN ISO 13849-1
|
-
|
|
Certified for UL hazardous location division 1
|
-
|
|
Certified for UL hazardous location division 2
|
-
|
|
Supporting protocol for AS-Interface Safety at Work
|
no
|
|
Certified for UL hazardous location group D (propane)
|
-
|
|
Certified for UL hazardous location group B (hydrogen)
|
-
|
|
Certified for UL hazardous location group C (ethylene)
|
-
|
|
Fieldbus connection over separate bus coupler possible
|
yes
|
|
Certified for UL hazardous location group A (acetylene)
|
-
|
|
Certified for UL hazardous location group E (metal dusts)
|
-
|
|
Certified for UL hazardous location group F (carbonaceous dusts)
|
-
|
|
Certified for UL hazardous location group G (non-conductive dusts)
|
-
|
