Popularity Top 10%

Among the top 10% of products bought or added to a distributor basket on Voltimum UK in the last 12 months, based on distributor sales. Popularity is not a customer review. Voltimum does not collect product ratings. It reflects how often electrical professionals bought this product through participating wholesalers or added it to a distributor basket on Voltimum UK, compared with other products in the catalogue. Updated nightly.

Light block, Harmony XB4, Harmony XB5, for head 22mm, universal LED, screw clamp terminals, 230...240V AC

Link copied

SKU
EAN
GTIN
MPN

Light block, Harmony XB4, Harmony XB5, for head 22mm, universal LED, screw clamp terminals, 230...240V AC by Schneider Electric is listed by 7 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, Control Components Anglia, Farnell and 4 more. It is currently in stock at all of them. Trade prices range from £12.53 to £20.11 excl. VAT. Voltimum+ members earn 3 points per unit.

This Harmony ZB, white light block operates with a universal LED. It is supplied with 230V to 240V AC and uses screw clamp terminals. It has a plastic body. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push-button or selector switch units via clip together assembly and connected with simple screw-clamp connections. It enables visual distinction of signaling units via illumination by universal LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. It features high endurance LED lighting for less replacement and process downtimes. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product. Vibration resistant screw clamp connection terminals ensure high vibration resistance making product suitable installation on high impact machine.

Loyalty points: 3

Price range: £ 12.53 - £ 20.11 Excl. VAT

ETIM group

Low-voltage industrial components

Specifications

Lamp type	LED
Lamp holder	None
Type of fastening	Front fastening
With light source	yes
Colour light source	White
With integrated diode	yes
Rated voltage Ue at DC
Transformer integrated	no
Voltage type for actuating	AC
Rated voltage Ue at AC 50 Hz
Rated voltage Ue at AC 60 Hz
Connection type auxiliary circuit	Screw connection
With integrated voltage decreasing resistor	no
