CONNECTOR 32A 5 MODULES
Canalis tap-off unit for KS. It's applied to medium power distribution and TT, IT and TN-S earthing system. The operational voltage is from 230VAC 50/60Hz to 690VAC 50/60Hz. The rated operational current is 32A. Mounting by Plug-in with fixed polarity with white RAL 9001 surface treatment and whose busbar trunking polarity is 3L+N+PE. It provided protection for miniature circuit breaker (MCB) (Circuit breaker to be ordered separately). It provided tap-off unit disconnection by drawing out with front door/cover opening. Canalis KS busbar trunking compatibility with plug-in outlets. It provides IP55 protection which conforming to IEC 60529 standard. IK08 conforms to IEC 62262. It is compliant with both IEC 61439-1 and IEC 61439-6. It is compliant with Schneider Electric Environmental Data Program (RoHS, REACh, Product Environmental Profile, End of Life Instructions).
Product identifiers
SKU: KSB32CM55
EAN: 3606480005978
GTIN: 3606480005978
MPN: KSB32CM55
Loyalty points:
45
Price: £ 119.87 Excl. VAT
Categories
Features
|
Width
|
108 mm
|
|
Colour
|
White
|
|
Height
|
175 mm
|
|
Length
|
135 mm
|
|
Protection
|
None
|
|
RAL-number
|
9001
|
|
With locking
|
no
|
|
Branch off type
|
Pipe in-lead
|
|
Number of poles
|
5
|
|
Phase selection
|
no
|
|
Rated current AC 50 Hz
|
32 A
|
|
Rated voltage AC 50 Hz
|
|
|
Type of socket outlets
|
Other
|
|
Degree of protection (IP)
|
IP55
|
|
Degree of protection (NEMA)
|
-
|
|
Number of NEMA socket outlets
|
0
|
|
Number of other socket outlets
|
0
|
|
Number of conductors (without earthing)
|
4
|
|
Number of CEE socket outlets (IEC 60309)
|
0
|
