Schneider Electric

Electronic thermal overload relay, TeSys Giga, 28…115 A, class 5E…30E, push-in control connection

Electronic thermal overload relay, TeSys Giga, 28…115 A, class 5E…30E, push-in control connection by Schneider Electric is listed by 2 electrical wholesalers on Voltimum UK, including RS Components and Rexel Group. It is currently in stock at all of them. Trade price £278.73 excl. VAT. Voltimum+ members earn 37 points per unit.

TeSys LR9G 115A thermal overload relay is compatible with TeSys Giga high power contactor, push-in control connection. It provides phase imbalance, phase failure, in-built ground-fault and single-phase loads protections. It is available for manual and auto reset options and LED indicator for Motor ON and pre-trip alarm. Tripping classes is selectable from class 5E to class 30E to suit different application needs from fast tripping, general purpose and high inertia loads. It is suitable for independent mounting or direct mounting with LC1G contactors. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature without derating up to 3000m altitude. Multi standards certified (CE,CB,CCC,cULus,EAC,KC,RCM,Marine). Unique QR code provides quick access to complete product data.

Product identifiers

SKU: LR9G115
EAN: 3606481920270
GTIN: 3606481920270
MPN: LR9G115

Voltimum+ Loyalty Programme Loyalty points: 37

Price: £ 278.73 Excl. VAT

Categories

Contactors & Motor Starters Switchgear & Circuit Protection

ETIM group

Low-voltage industrial components

Specifications

Release class CLASS 10
Mounting method Direct attachment/single positioning
Reset function input yes
Adjustable current range
Reset function automatic yes
Reset function push-button yes
Max. rated operation voltage Ue 1000 V
Type of electrical connection of main circuit Screw connection
Number of auxiliary contacts as normally open contact 1

Documents

Deeplink product page

Open

Environmental compliance declaration

LR9G115 REACh Declaration

Open

User guide

TeSys Giga Series - Contactors and Electronic Overload Relays - Installation Guide

Open

Instruction sheet

OLR Mounting Base Instruction Sheet

Open

Product data sheet

Open

Catalogue

TeSys - Catalog 2025 - Innovative and connected solutions for motor starters

Open

Environmental compliance declaration

LR9G115 EU RoHS Declaration

Open

Environmental compliance declaration

LR9G115 China RoHS Declaration

Open
