TeSys D contactor - 3P(3 NO) - AC-3 - <= 440 V 32 A - 200 V AC coil
1 / 5
TeSys D contactor - 3P(3 NO) - AC-3 - <= 440 V 32 A - 200 V AC coil
TeSys D contactor - 3P(3 NO) - AC-3 - <= 440 V 32 A - 200 V AC coil by Schneider Electric is listed by 3 electrical wholesalers on Voltimum UK, including Control Components Anglia, Farnell and RS Components. It is currently in stock at 1 of them. Trade prices range from £151.40 to £152.91 excl. VAT. Voltimum+ members earn 20 points per unit.
TeSys D contactor, 3 poles (3NO), for motor control applications up to 32A/690V AC-3/3e (15kW@400V). It provides a 200V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by lugs-ring terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine).
Product identifiers
SKU: LC1D326L7
EAN: 3389110805239
GTIN: 3389110805239
MPN: LC1D326L7
Loyalty points:
20
Price range: £ 151.40 - £ 152.91 Excl. VAT
ETIM group
Specifications
| Depth | 92 mm |
| Width | 45 mm |
| Height | 85 mm |
| Modular version | no |
| Operating voltage AC 50 Hz | |
| Operating voltage AC 60 Hz | |
| Rated operation power NEMA | - |
| Voltage type for actuating | AC |
