Popularity Top 30%

Among the top 30% of products bought or added to a distributor basket on Voltimum UK in the last 12 months, based on distributor sales. Popularity is not a customer review. Voltimum does not collect product ratings. It reflects how often electrical professionals bought this product through participating wholesalers or added it to a distributor basket on Voltimum UK, compared with other products in the catalogue. Updated nightly.

Emergency stop head, switching off, metal, red mushroom Ø40, Ø22, trigger latching key release

Link copied

SKU
EAN
GTIN
MPN

Emergency stop head, switching off, metal, red mushroom Ø40, Ø22, trigger latching key release by Schneider Electric is listed by 7 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, Control Components Anglia, Farnell and 4 more. It is currently in stock at all of them. Trade prices range from £23.56 to £37.81 excl. VAT. Voltimum+ members earn 5 points per unit.

This Harmony XB4, Emergency stop 40mm mushroom red button head operates with a latched key-to-release (key no.455) mechanism. This emergency stop / shutdown button head, is easily combined with contact blocks and installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance thanks to a clear color and a prominent 40mm mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K. It has a metal bezel, this makes it Ideal for applications requiring high impact and vibration resistance. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Secure machine and system operation with a key, only available to authorized operators. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.

Loyalty points: 5

Price range: £ 23.56 - £ 37.81 Excl. VAT

ETIM group

Low-voltage industrial components

Specifications

Diameter cap	40 mm
Colour button	Red
Hole diameter	22.5 mm
Spring-return	no
Width opening	-
With lighting	no
Height opening	-
Type of button	High
With front ring	yes
Unlocking method	Key-release
Colour front ring	Chrome
Material front ring	Metal
Supply voltage lamp	-
Suitable for lighting	no
Construction type lens	Round
Degree of protection (IP)	IP66
Degree of protection (NEMA)	13
Suitable for emergency stop	yes
Switching function latching	yes
