Single contact block for head Ø22 1NC late break screw clamp terminal

Link copied

SKU
EAN
GTIN
MPN

Single contact block for head Ø22 1NC late break screw clamp terminal by Schneider Electric is listed by 6 electrical wholesalers on Voltimum UK, including BPX Electro Mechanical Co. Ltd, Control Components Anglia, Farnell and 3 more. It is currently in stock at 4 of them. Trade prices range from £5.64 to £9.83 excl. VAT. Voltimum+ members earn 1 point per unit.

This Harmony ZB, single contact block for staggered late break contact uses screw-clamp terminals. It is compatible with Harmony XB4 and XB5 control and signaling units. This contact block, uses for staggered late break contact operation, allows fast and easy replacement and configuration of specific control and signaling products. It is easily installed and replaced on XB4 and XB5 control and signalling units and connects to control circuits with screw-clamp connections. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. 1 million cycle high endurance under 6A load allows less maintenance and damage in your installation. It has clear color scheme for NO and NC contact block types. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.

Loyalty points: 1

Price range: £ 5.64 - £ 9.83 Excl. VAT

ETIM group

Low-voltage industrial components

Specifications

Model	Clip-on
Lamp holder	None
Mounting method	Front fastening
Type of electric connection	Screw connection
Number of fault-signal switches	0
Number of contacts as change-over contact	0
Rated operation current Ie at AC-15, 230 V	3 A
Number of contacts as normally open contact	0
Number of contacts as normally closed contact	1
