| EFNA0008 |
V0 |
| Contact type |
Pin |
| Rated voltage |
320 |
| Housing colour |
Orange |
| Coating housing |
Uncoated |
| Number of poles |
2 |
| Housing material |
Plastic |
| Material contact |
Other copper alloys |
| Pollution degree |
2 |
| Rated current In |
12 |
| Type of connection |
Printed circuit board to cable |
| Rated surge voltage |
4 |
| Operating temperature |
-60 - 100 |
| Over voltage category |
III |
| Connectable cable type |
Tubular cable |
| Material insulation body |
Thermoplastic |
| Modular spacing contacts |
5 |
| With protective conductor |
no |
| Material of contact surface |
Tin |
| Modular spacing connections |
5.08 |
| Type of electric connection |
Spring clamp connection |
| RAL-number (similar) housing |
- |
| Number of plug-in contact rows |
1 |
| Angle contact/conductor connection |
180° (horizontal) |
| Degree of protection (IP), mounted |
IP10 |
| Connectable conductor cross section solid-core |
0.08 - 2.5 |
| Connectable conductor cross section multi-wired |
0.08 - 2.5 |
| Connectable conductor cross section fine-strand with cable end sleeve |
0.25 - 1.5 |
| Connectable conductor cross section fine-strand without cable end sleeve |
0.08 - 2.5 |
